Resolution:

0.1 NTU

Accuracy:

Up to ± 5 NTU below 100 NTU

Response Time:

< 5 sec.

Linearity:

better than ± 2 %

Display:

Yellow Graphic Display

Datalogging System:

Yes

Power Supply / Consumption:

24 V AC or DC ± 10% / <5 VA

Alarm Points 1, 2:

Adjustable, (Works adjustment 50 NTU)

Alarm 1 Operating Delay: (for annunciation purpose)

Adjustable between 1 – 540 sec. (Works adjustment 2 sec.)

Alarm 2 Operating Delay: (for control purposes)

Adjustable between 1 – 10 sec. (Works adjustment 10 sec.)

Alarm Indication: (Alarm 1, 2, System Fault)

Red LEDs

Alarm Contact Rating: (Alarm 1, 2,)

Potential free 1 pole change over contacts, 3 A / 240 V AC

Output Signal:

0 – 20 mA or 4-20 mA selectable, ext. Load < 150 Ω

Sample Pressure:

0 – 10 bar

Sample Flow:

Approx. 0.3 - 3 l/min

Sample Temperature:

+ 1 to + 65° C

Ambient Temperature:

+ 1 to + 55° C

Size: Computer Unit

185 mm W x 210 mm H x 65 mm D

Size: Measuring Cell

140 mm W x 160 mm H x 65 mm D

Weight:

2.5 kg

Degree of Protection:

IP 65

Pipe Connections:

R ¼" Female
